拟解决的关键问题是：

1、系统设计和实现方面问题

推荐系统经过多年的发展已经在国内有相对较完善的开发设计思路和步骤，基于本次系统设计和实现，需要解决的问题可以分为五层：数据层、算法层、业务层、表现层、用户层。

1. 数据层：如何获取足量的数据同时整合MongoDB、MySQL、Redis和HDFS等多种数据存储系统，以支持系统对不同类型数据的存储和检索；
2. 算法层：如何设计并优化基于用户画像的推荐算法；
3. 业务层：如何设计用户管理、电影管理、推荐管理，用户操作管理等模块；
4. 表现层：作为面向用户的层面，应该考虑的是如何设计用户友好的系统界面，应该用到那些计算机技术；
5. 用户层：为了实现区分和管理不同用户类型，应思考有哪些用户类型，各类型的用户有哪些需求和权限管理。

2、论文编写方面问题

编写论文作为毕业设计中最为重要的环节之一，基于其撰写的重要性有以下几点问题：

1. 文献综述问题：如何在论文中进行文献综述，对现有的电影推荐系统研究和系统设计方法进行概述。首先，回顾和分析已有文献中的各种电影推荐系统，包括但不限于基于协同过滤、内容过滤、深度学习等不同方法的系统。通过深入研究这些系统，将评估它们在个性化推荐、实时性、用户体验等方面的优点和不足；
2. 方法论问题：如何清晰地描述系统设计的方法和流程，包括数据处理、算法实现、业务模块设计和用户界面构建，以便读者能够理解研究的具体实施步骤；
3. 实验设计问题：如何设计和执行实验证明，验证系统的有效性和性能，并提供可靠的实验结果以支持论文的结论；
4. 创新点突出问题：如何突出论文的创新点，包括在系统设计和算法层面的创新，以及如何解决现有电影推荐系统中的挑战和问题。

核心算法代码分享如下：

import ast
import collections
import datetime
import findspark
findspark.init()
import math
import numpy as np
import pandas as pd
from pyspark import Row, SparkContext, SparkConf
from pyspark.sql import SQLContext
from pyspark.sql.functions import col

# 该文件为系统的电影推荐的spark离线处理脚本
# 可放置linux下单独运行，只需在liunx下安装python3同时安装相应的库即可运行
# 当然也可放置在windows下运行，但环境配置较复杂容易出错，不建议
# 内部需要改动mysql数据库配置信息（33行、34行、36行）、spark信息（24行）、hadoop信息（39行）
# 注：该脚本做了数据量的限制，于  221行 可以取消数据量的限制
# 执行完成后会将数据更新到表“user_usermovierecommend”，同时在hadoop中路径movie_system会生成计算的相关相似度文件
# 算法参考 recommenderSystemBasedOnSpark 项目：XXXXX


class Calculator:
    def __init__(self):
        self.localClusterURL = "local[2]"
        self.clusterMasterURL = "spark://master:7077"
        self.conf = SparkConf().setAppName('Movie_System').setMaster(self.clusterMasterURL)
        self.sc = SparkContext.getOrCreate(self.conf)
        self.sqlContext = SQLContext(self.sc)
        # spark 初始化
        # self.sqlContext = SparkSession.Builder().appName('sql').master('spark://Spark:7077').getOrCreate()

        # mysql 配置
        self.prop = {'user': '127_0_0_1',
                     'password': 'RjHysK3TfjSdGwmJ',
                     'driver': 'com.mysql.cj.jdbc.Driver'}
        self.jdbcURL = "jdbc:mysql://172.19.107.58:3306/127_0_0_1" \
                       "?useUnicode=true&characterEncoding=utf-8&useSSL=false"

        #  user\rating\links\tags在hdfs中的位置 ===> 即推荐原料在hdfs中的存档路径
        self.hdfs_data_path = 'hdfs://master:9000/movie_system/'

        self.date_time = datetime.datetime.now().strftime("%Y-%m-%d")

    def __del__(self):
        # 关闭spark会话
        self.sc.stop()
        del self.sc

    def select(self, sql):
        # 读取表
        data = self.sqlContext.read.jdbc(url=self.jdbcURL, table=sql, properties=self.prop)
        return data
        # # 离线计算时从mysql加载movies数据到hive中
        # movies_sql = self.sqlContext.read.format('jdbc') \
        #     .options(url=self.jdbcURL,
        #              driver=self.prop['dirver'],
        #              dbtable=self.movieTab,
        #              user=self.prop['user'],
        #              password=self.prop['password']).load()

    def get_data(self, path):
        data = self.sqlContext.read.parquet(path)
        return data

    # def show(self):
    #     sql = '(select user_id,tag_type,tag_weight,tag_name from user_usertag) aaa'
    #     data = self.select(sql)
    #     # 打印data数据类型  <class 'pyspark.sql.dataframe.DataFrame'>
    #     # print(type(data))
    #     # 展示数据
    #     data.show()

    def write(self, data, path):
        data.write.csv(path + "_csv", header=True, sep=",", mode='overwrite')
        data.write.parquet(path, mode='overwrite')

    def change_sql_data_to_hdfs(self, sql, path):
        data = self.select(sql)
        self.write(data, path)

    # 根据电影类型、语言、国家、年份计算相似度
    def calculator_movie_type(self, read_path, write_path):
        dfMovies = self.get_data(read_path)
        dfMovies.show()
        """计算两个rdd的笛卡尔积"""
        rddMovieCartesianed = dfMovies.rdd.cartesian(dfMovies.rdd)
        rddMovieIdAndGenre = rddMovieCartesianed.map(lambda line: Row(movie1=line[0]['movie_id'],
                                                                      movie2=line[1]['movie_id'],
                                                                      sim=countSimBetweenTwoMovie(line[0], line[1])))
        dfFinal = self.sqlContext.createDataFrame(rddMovieIdAndGenre)
        dfFinal.show()
        self.write(dfFinal, write_path)

    # 根据用户喜好、兴趣、年龄、城市计算相似度
    def calculator_user_base(self, read_path, write_path):
        dfUsers = self.get_data(read_path)
        dfUsers.show()
        """计算两个rdd的笛卡尔积"""
        rddUserCartesianed = dfUsers.rdd.cartesian(dfUsers.rdd)
        rddUserIdAndGenre = rddUserCartesianed.map(lambda line: Row(user1=line[0]['user_id'],
                                                                    user2=line[1]['user_id'],
                                                                    sim=countSimBetweenTwoUser(line[0], line[1])))
        dfFinal = self.sqlContext.createDataFrame(rddUserIdAndGenre)
        dfFinal.show()
        self.write(dfFinal, write_path)

    # 根据用户的标签进行计算相似度
    def calculator_user_tag(self, read_path, write_path):
        dfUsers = self.get_data(read_path)
        # dfUsers.show()
        # print(change_user_tag_data(dfUsers.toPandas()))
        dfUsers = self.sqlContext.createDataFrame(change_user_tag_data(dfUsers.toPandas()))
        # dfUsers.show()
        # """计算两个rdd的笛卡尔积"""
        rddUserCartesianed = dfUsers.rdd.cartesian(dfUsers.rdd)
        rddUserIdAndGenre = rddUserCartesianed.map(lambda line: Row(user1=line[0]['user_id'],
                                                                    user2=line[1]['user_id'],
                                                                    sim=countSimBetweenTwoUserByTag(line[0], line[1])))
        dfFinal = self.sqlContext.createDataFrame(rddUserIdAndGenre)
        # dfFinal.show()
        self.write(dfFinal, write_path)

    @staticmethod
    def change_dataframe_to_li(data_frame, li_name):
        data_frame = data_frame.toPandas()
        data_li = np.array(data_frame[li_name])
        data_li = data_li.tolist()
        return data_li

    # 查找相似的电影
    def select_movie_to_movie(self, df_sim_movie, movie_id):
        min_sim = 0.5
        max_num = 300
        df_sim_movie = df_sim_movie.orderBy('sim', ascending=0)\
            .where(
                   (col('movie1') == movie_id) &
                   (col('sim').__ge__(min_sim)) &
                   (col('movie1') != col('movie2')))\
            .limit(max_num).select('movie2')
        df_sim_movie_li = self.change_dataframe_to_li(df_sim_movie, "movie2")
        return df_sim_movie_li

    # 查找相似的用户
    def select_user_to_user(self, df_sim_user, user_id):
        min_sim = 0.5
        max_num = 300
        df_sim_user = df_sim_user.orderBy('sim', ascending=0)\
            .where(
                   (col('user1') == user_id) &
                   (col('sim').__ge__(min_sim)) &
                   (col('user1') != col('user2')))\
            .limit(max_num).select('user2')
        df_sim_user_li = self.change_dataframe_to_li(df_sim_user, "user2")
        return df_sim_user_li

    # 查询用户收藏、评论、评分良好的电影
    def select_user_movie(self, df_users, user_id):
        min_score = 3
        max_num = 300
        df_movies = df_users.orderBy('tag_weight', ascending=0) \
            .where((
                    (col('tag_type') == 'like_movie_id') |
                    (col('tag_type') == 'rating_movie_id') |
                    (col('tag_type') == 'comment_movie_id')
                    # (col('tag_type') == 'rating_movie_id')
                   ) & (col('tag_weight').__ge__(min_score)) & (col('user_id').__eq__(user_id))) \
            .limit(max_num).select('tag_name').distinct()
        movie_li = self.change_dataframe_to_li(df_movies, "tag_name")
        # movie_li = np.array(df_movies.toPandas()["tag_name"])
        # movie_li = movie_li.tolist()
        return movie_li

    def calculator_user_movie_recommend(self, user_path, tag_path, movie_sim_path, user_sim_path, calculator_type):
        finial_rs = list()
        # 取出用户信息user_id数据
        df_users = self.get_data(user_path).select('user_id')
        df_users.show()
        # 读取用户标签信息
        df_tag_users = self.get_data(tag_path)
        df_tag_users.show()
        # 读取电影相似度数据
        df_movie_sim = self.get_data(movie_sim_path)
        df_movie_sim.show()
        # 读取用户相似度数据
        df_user_sim = self.get_data(user_sim_path)
        df_user_sim.show()

        user_id_li = self.change_dataframe_to_li(df_users, "user_id")

        if calculator_type == "movie":   # 根据电影查找电影
            for id, user_id in enumerate(list(user_id_li)):
                user_movie_li = self.select_user_movie(df_tag_users, user_id)
                user_movie_li_rs = list()
                for user_movie_id in list(user_movie_li):
                    select_movie_to_movie_li = list(self.select_movie_to_movie(df_movie_sim, user_movie_id))
                    user_movie_li_rs = list(set(select_movie_to_movie_li + user_movie_li_rs))  # 合并List
                user_movie_li_rs = "，".join(map(str, user_movie_li_rs))  # 转成字符串
                finial_rs.append([id, user_id, user_movie_li_rs, datetime.datetime.now().strftime('%Y-%m-%d %H:%M:%S')])
        elif calculator_type == "user":  # 根据用户查找电影
            for id, user_id in enumerate(list(user_id_li)):
                user_id_li_rs = self.select_user_to_user(df_user_sim, user_id)
                user_movie_li_rs = list()
                for user_id_rs in list(user_id_li_rs):
                    select_user_to_movie_li = list(self.select_user_movie(df_tag_users, user_id_rs))
                    user_movie_li_rs = list(set(select_user_to_movie_li + user_movie_li_rs))  # 合并List
                user_movie_li_rs = "，".join(map(str, user_movie_li_rs))  # 转成字符串
                finial_rs.append([id, user_id, user_movie_li_rs, datetime.datetime.now().strftime('%Y-%m-%d %H:%M:%S')])

        # print(finial_rs)
        # 将数据转换
        recommend = self.sqlContext.createDataFrame(finial_rs, ["id", "user_id", "movie_id_li", "create_time"])
        # 写入数据库
        recommend.write.jdbc(url=self.jdbcURL, table='user_usermovierecommend', mode='overwrite', properties=self.prop)

    # 将数据从数据库中取出，并以parquet文件格式写入到HDFS里
    def step_1(self):
        sql1 = '(select user_id,tag_type,tag_weight,tag_name from user_usertag) user_tag_base'
        path1 = self.hdfs_data_path + 'user_tag_base_'+self.date_time
        self.change_sql_data_to_hdfs(sql1, path1)
        # 测试时限制数量防止计算量过大
        sql2 = '(SELECT `movie_id`,`title`,`rating`,`genres`,`countries`,`languages`,`year` FROM ' \
               'movie_collectmoviedb limit 0,1000) movie_base'
        path2 = self.hdfs_data_path + 'movie_base_'+self.date_time
        self.change_sql_data_to_hdfs(sql2, path2)
        # 用户信息
        sql3 = '(select d.id user_id, b.user_gender gender, d.user_age age, d.user_prefer prefers, ' \
               'd.user_hobbies hobbies, d.user_province province, d.user_city city, d.user_district district ' \
               'from user_usersbase b join user_usersdetail d on b.id = d.user_id_id where b.user_status = 1) user_base'
        path3 = self.hdfs_data_path + 'user_base_'+self.date_time
        self.change_sql_data_to_hdfs(sql3, path3)

    # 读取parquet文件，然后计算相似度
    def step_2(self):
        read_path1 = self.hdfs_data_path + 'user_tag_base_'+self.date_time
        write_path1 = self.hdfs_data_path + 'user_tag_simContent_' + self.date_time
        read_path2 = self.hdfs_data_path + 'movie_base_' + self.date_time
        write_path2 = self.hdfs_data_path + 'movie_simContent_' + self.date_time
        read_path3 = self.hdfs_data_path + 'user_base_'+self.date_time
        write_path3 = self.hdfs_data_path + 'user_simContent_' + self.date_time
        self.calculator_movie_type(read_path2, write_path2)
        self.calculator_user_base(read_path3, write_path3)
        self.calculator_user_tag(read_path1, write_path1)

    # 读取parquet相似度数据，然后生成推荐内容，存储到mysql和HDFS
    def step_3(self):
        user_base_path = self.hdfs_data_path + 'user_base_'+self.date_time
        user_tag_base_path = self.hdfs_data_path + 'user_tag_base_'+self.date_time
        movie_sim_path = self.hdfs_data_path + 'movie_simContent_' + self.date_time
        user_sim_path = self.hdfs_data_path + 'user_tag_simContent_'+self.date_time

        # 根据相似用户进行推荐
        # self.calculator_user_movie_recommend(user_base_path, user_tag_base_path,
        #                                      movie_sim_path, user_sim_path, "user")

        # 根据相似电影进行推荐
        self.calculator_user_movie_recommend(user_base_path, user_tag_base_path,
                                             movie_sim_path, user_sim_path, "movie")


def countIntersectionForTwoSets(list1, list2):
    """计算两个集合的交集的模"""
    count = 0
    for i in range(len(list1)):
        m = list1[i]
        for j in range(len(list2)):
            if list2[j] == m:
                count = count + 1
                break
    return count


def countSimBetweenTwoList(list1, list2):
    s1 = len(list1)
    s2 = len(list2)
    m = math.sqrt(s1 * s2)
    if m == 0:
        if s1 == 0 and s2 == 0:
            return 1
        else:
            return 0
    return countIntersectionForTwoSets(list1, list2) / m


def countSimBetweenTwoMovie(list1, list2):
    """计算两个Movie的相似度"""
    movie_type_list1 = ast.literal_eval(list1['genres'])
    movie_type_list2 = ast.literal_eval(list2['genres'])
    movie_country_list1 = ast.literal_eval(list1['countries'])
    movie_country_list2 = ast.literal_eval(list2['countries'])
    movie_language_list1 = ast.literal_eval(list1['languages'])
    movie_language_list2 = ast.literal_eval(list2['languages'])
    movie_year1 = list1['year']
    movie_year2 = list2['year']
    movie_year = 1 if movie_year1 == movie_year2 else 0
    movie_type = countSimBetweenTwoList(movie_type_list1, movie_type_list2)
    movie_country = countSimBetweenTwoList(movie_country_list1, movie_country_list2)
    movie_language = countSimBetweenTwoList(movie_language_list1, movie_language_list2)
    sim = (movie_type * 5 + movie_country * 2 + movie_language * 2 + movie_year * 1) / 10
    return sim


def countSimBetweenTwoUser(list1, list2):
    """计算两个User的相似度"""
    user_prefer_list1 = list1['prefers'].split(",") if list1['prefers'] != '' and list1['prefers'] is not None else []
    user_prefer_list2 = list2['prefers'].split(",") if list2['prefers'] != '' and list2['prefers'] is not None else []
    user_hobbie_list1 = list1['hobbies'].split(",") if list1['hobbies'] != '' and list1['hobbies'] is not None else []
    user_hobbie_list2 = list2['hobbies'].split(",") if list2['hobbies'] != '' and list2['hobbies'] is not None else []
    user_gender = 1 if list1['gender'] == list2['gender'] else 0
    user_province = 1 if list1['province'] == list2['province'] else 0
    user_city = 1 if list1['city'] == list2['city'] else 0
    user_district = 1 if list1['district'] == list2['district'] else 0
    user_prefer = countSimBetweenTwoList(user_prefer_list1, user_prefer_list2)
    user_hobbie = countSimBetweenTwoList(user_hobbie_list1, user_hobbie_list2)
    sim = (user_prefer * 5 + user_hobbie * 2 + user_gender * 1 + user_province * 1 +
           user_city * 0.5 + user_district * 0.5) / 10
    return sim


def countSimBetweenTwoDict(info_movie_tag1_dict, info_movie_tag2_dict):
    if not info_movie_tag1_dict and not info_movie_tag2_dict or info_movie_tag1_dict == info_movie_tag2_dict:
        return 1
    key_li1 = list(info_movie_tag1_dict.keys())
    key_li2 = list(info_movie_tag2_dict.keys())
    content_sim = countSimBetweenTwoList(key_li1, key_li2)
    key_score = 0
    if key_li1 and key_li2 and key_li1[0] == key_li2[0]:
        key_score += 5
    if len(key_li1) >= 2 and len(key_li2) >= 2 and key_li1[1] == key_li2[1]:
        key_score += 3
    if len(key_li1) >= 3 and len(key_li2) >= 3 and key_li1[2] == key_li2[2]:
        key_score += 2
    key_score = (content_sim + key_score / 10) / 2
    return key_score


def countSimBetweenTwoUserByTag(list1, list2):
    """计算两个User的相似度"""
    # info_age、info_city、info_phone_city、info_province、info_sex
    # info_movie_tag、info_movie_type
    # List：like_movie_id、info_hobbies、rating_movie_id

    user_tag_list1 = ast.literal_eval(list1['user_data'])
    user_tag_list2 = ast.literal_eval(list2['user_data'])
    info_age1 = user_tag_list1.get("user_info").get("info_age")
    info_city1 = user_tag_list1.get("user_info").get("info_city")
    info_phone_city1 = user_tag_list1.get("user_info").get("info_phone_city")
    info_province1 = user_tag_list1.get("user_info").get("info_province")
    info_sex1 = user_tag_list1.get("user_info").get("info_sex")
    info_movie_tag1_dict = user_tag_list1.get("info_movie_tag")
    info_movie_type1_dict = user_tag_list1.get("info_movie_type")
    like_movie_id1_li = user_tag_list1.get("like_movie_id")
    info_hobbies1_li = user_tag_list1.get("info_hobbies")
    rating_movie_id1_li = user_tag_list1.get("rating_movie_id")

    info_age2 = user_tag_list2.get("user_info").get("info_age")
    info_city2 = user_tag_list2.get("user_info").get("info_city")
    info_phone_city2 = user_tag_list2.get("user_info").get("info_phone_city")
    info_province2 = user_tag_list2.get("user_info").get("info_province")
    info_sex2 = user_tag_list2.get("user_info").get("info_sex")
    info_movie_tag2_dict = user_tag_list2.get("info_movie_tag")
    info_movie_type2_dict = user_tag_list2.get("info_movie_type")
    like_movie_id2_li = user_tag_list2.get("like_movie_id")
    info_hobbies2_li = user_tag_list2.get("info_hobbies")
    rating_movie_id2_li = user_tag_list2.get("rating_movie_id")

    if (info_age1 and info_age2 and int(info_age1) in range(int(info_age2)-3, int(info_age2)+3)) or \
            (not info_age1 and not info_age2):
        info_age = 1
    else:
        info_age = 0

    info_city = is_exist_and_equal(info_city1, info_city2)
    info_sex = is_exist_and_equal(info_sex1, info_sex2)
    info_phone_city = is_exist_and_equal(info_phone_city1, info_phone_city2)
    info_province = is_exist_and_equal(info_province1, info_province2)
    like_movie_id_li = is_exist_and_equal_li(like_movie_id1_li, like_movie_id2_li)
    info_hobbies_li = is_exist_and_equal_li(info_hobbies1_li, info_hobbies2_li)
    rating_movie_id_li = is_exist_and_equal_li(rating_movie_id1_li, rating_movie_id2_li)
    if (info_movie_tag1_dict and info_movie_tag2_dict) or (not info_movie_tag1_dict and not info_movie_tag2_dict):
        info_movie_tag_dict = countSimBetweenTwoDict(info_movie_tag1_dict, info_movie_tag2_dict)
    else:
        info_movie_tag_dict = 0
    if (info_movie_type1_dict and info_movie_type2_dict) or (not info_movie_type1_dict and not info_movie_type2_dict):
        info_movie_type_dict = countSimBetweenTwoDict(info_movie_type1_dict, info_movie_type2_dict)
    else:
        info_movie_type_dict = 0
    sim = (info_movie_tag_dict * 2 + info_movie_type_dict * 2 + like_movie_id_li * 1 + info_hobbies_li * 1 +
           rating_movie_id_li * 1 + info_age * 1 + info_city * 0.5 + info_sex * 0.5 + info_phone_city * 0.5 +
           info_province * 0.5) / 10
    return sim


def is_exist_and_equal_li(str1, str2):
    if not str1 and not str2:
        return 1
    if str1 and str2:
        return countSimBetweenTwoList(str1, str2)
    else:
        return 0


def is_exist_and_equal(str1, str2):
    # if (str1 and str2 and str2 == str1) or (not str1 and not str2):
    if str2 == str1:
        return 1
    else:
        return 0


# 将用户的数据进行格式化
def change_user_tag_data(data):
    list_tag = ["like_movie_id", "info_hobbies", "rating_movie_id"]
    dict_tag = ["info_movie_tag", "info_movie_type"]
    all_user_data_rs = list()
    for user_data in data.groupby(["user_id"]):
        user_data_rs = dict()
        user_id = user_data[0]
        user_data_rs["user_id"] = user_id
        user_tag_rs = dict()
        user_info_dict = dict()
        for user_tag_data in pd.DataFrame(user_data[1]).drop("user_id", axis=1).groupby(["tag_type"]):
            if user_tag_data[0] in dict_tag:
                #             print(user_data[1])
                info_movie_tag = pd.DataFrame(user_tag_data[1]).drop(["tag_type"], axis=1).sort_values("tag_weight",
                                                                                                       ascending=False)
                info_movie_tag = collections.OrderedDict(zip(info_movie_tag["tag_name"], info_movie_tag["tag_weight"]))
                user_tag_rs[user_tag_data[0]] = dict(info_movie_tag)
            #             print(dict(info_movie_tag))
            elif user_tag_data[0] in list_tag:
                #             print(user_data[1])
                like_movie_id = pd.DataFrame(user_tag_data[1]).drop(["tag_type"], axis=1).sort_values("tag_weight",
                                                                                                      ascending=False)
                like_movie_id = list(like_movie_id["tag_name"])
                user_tag_rs[user_tag_data[0]] = like_movie_id
            #             print(like_movie_id)
            else:
                user_info = pd.DataFrame(user_tag_data[1]).drop(["tag_weight"], axis=1)
                user_info_dict[user_info["tag_type"].values[0]] = user_info["tag_name"].values[0]
        user_tag_rs["user_info"] = user_info_dict
        user_data_rs["user_data"] = str(user_tag_rs)
        all_user_data_rs.append(user_data_rs)
    # print(all_user_data_rs)
    # return all_user_data_rs
    return pd.DataFrame(all_user_data_rs)


# 将数据从数据库中取出，并以parquet文件格式写入到HDFS里
calculator = Calculator()
try:
    # 从HDFS中读取出
    calculator.step_1()
    calculator.step_2()
    calculator.step_3()
except Exception as ex:
    print(ex)
    # 终止程序
    calculator.sc.stop()
calculator.sc.stop()
